Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6

Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6

Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6
Product Details:
Place of Origin: Jiangsu, China
Brand Name: Eceng
Certification: CE ISO
Model Number: K6
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $35,800.00/Sets 1-1 Sets
Packaging Details: standard export wooden case or according to your requirements
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set/Sets per Year
Contact Now
Detailed Product Description
Bottle Volume(ml): 2000 Ml Application: Bottle
Blow Moulding Type: Stretch Blow Moulding PLC Brand: DELTA
Applicable Industries: Manufacturing Plant Output: 10000
Power(W): 50KW Port: Shanghai
High Light:

Energy Saving Bottle Blowing moulding Machine

,

K6 Bottle Blowing moulding Machine

,

Water Bottle Blowing Machine 50KW

Energy Saving Water Bottle Blowing Machine for Manufacturing K6Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 0
specification
             Model                                                                    K6






Bottle type specification
Cavity
6

Max.volume
2L

Bottle mouth maximum overall diameter
28-30mm

Bottle biggest diameter
100mm

Bottle maximum height
330mm


Capacity specification
Theory output
9000~12000BPH

Bottle type volume
500ML

Bottle type weight
17g

Bottle type
Round



Power specification
Light tube quantity
32pcs

Light tube power
1.25KW

Maximum heating power
40KW

All electric machine installation
49KW

Actual consumption
30%--60%


Air pressure specification
Work pressure
5-6kg/cm2

Blow bottle pressure
25-45kg/cm2

Higher -pressure gas consumption
8000Ltr/min


Air pressure specification
Work pressure
5-6 kg/cm2

Temperature range
10℃

Consumption
8000kcal/hr

Forzen water flow
120L/min

Machine specification
Machine size
5.5x1.8x1.9

Machine weight
6.1ton



Water is an essential component of life as we know it. However, it's not just limited to drinking; people also use water to store and transport other liquids, such as juices and oils. This is where water bottles come in handy.
As the demand for bottled water, and other liquids, continues to grow, so too does the need for efficient and cost-effective machinery to produce bottles in large quantities. This is where the Eceng K6, a fully electric automatic blow molding machine, comes in.
With a maximum capacity of 12000 bottles per hour, the Eceng K6 is designed to cater to the high-volume needs of the water and beverage industry. The fully electric operation not only makes it more efficient but also more environmentally friendly.
One of the standout features of the Eceng K6 is its modular design, which allows for easy maintenance and repair. This not only saves time and money but also reduces downtime, ensuring that the machine is running efficiently for longer periods.
The fully automated operation of the machine also ensures high levels of consistency in bottle quality. This is important, especially for the beverage industry, where consistent bottle size and shape are essential for branding and packaging purposes.
In conclusion, the Eceng K6 is a state-of-the-art machine that efficiently produces large quantities of high-quality bottles in a cost-effective manner. Its fully electric operation and modular design make it a highly desirable option for the water and beverage industry, providing a reliable and sustainable solution for bottle production.



Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 2
Detailed Images
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 4
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 6
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 8
K linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.
Kseries linear bottle blowing machine features:
1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs.
4. manual and automatic methods of operation, human-machine interface control, simple operation.
5. servo transmission system, high positioning accuracy, fast speed stability and good reliability.
6. less than 0.2% scrap rate for finished bottle .
blowing mould
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 10
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 12
Company Introduction
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 14
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 16
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 18
Packing&Shipping
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 20
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 22
Normally the inner package, we will packed by the stretch film. Outer package we will use the export woodencase. Mostly we deliver the goods by sea as the freight is most reasonable in this way.
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 24
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 25
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 27
Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 29



Energy Saving Water Bottle Blowing Machine 50KW For Manufacturing K6 31
